25HP K600 EXTREME TWIN BED
MASSIVE INCREASE IN PRODUCTION WITHOUT a MASSIVE investment in machinery.
The 6th generation K600 Extreme Twin Bed is a fully automatic 5 Axis CNC Saw capable of rapid automated cutting of granite slabs and milling. The user-friendly touch screen allows easy programing and operation of the saw.
In addition to automated cutting and milling, this machine has an EXTREME buttressed steel wall design, two tilt tables, 725 series controls, and more. The Extreme has the power to get it done!
From hot galvanized frame work to the highest quality components, when you purchase a Sasso, you purchase a machine that is engineered to stand the test of time.
"The Twin never stops chopping...incredible!"
25HP K600 EXTREME TWIN BED
BUILT TO MAINTAIN CUTTING ACCURACY
The bridge is robust post tensioned steel with precision machined ways. The K600 5 Axis saw uses very precise servos to control the movement of the X, Y, C, A and Z axis.
FULLY ARTICULATED CUTTING AND MILLING HEAD
The cutting head rotates a full 360 degrees and miters from 0 degrees to 90. Includes M20 Adapter and 1/2 Gas Adapter
ALPHACAM CAD/CAM & COLLISION AVOIDANCE
All Sasso CNC Saws come with state of the art CAD/CAM software. The software is designed to make cutting and milling a simple, fast and productive for your machine operator.
EXCLUSIVE SASSO SUPER PLUNGE FEATURE
This revolutionary advancement allows the saw to plunge into the bed of the machine. Obtain greater slab yield as a result of tighter nesting of parts on the slab and DRAMATICALLY reduce mill time on sink corners and L shapes.
ADVANCED TOUCHSCREEN PC CONTROLS
Our large touch screen PC controls allow for orthogonal cutting, semi-automatic cutting and parametric cutting from the controls. It allows you to preview the project BEFORE you start cutting. You can access job files, the internet, remote tech support and any other tasks you can do on a computer. If you choose, you can install AlphaCam on the controls of the machine.
MILLING 3D EXOTIC SHAPES (FST SOFTWARE RECOMMENDED)
With the Sasso K600 you can make more than countertops. Three dimensional shapes can be milled, profiled and shaped. The only limit on what you can do is your imagination.
AUTO LUBRICATION SYSTEM
All motion control axises feature auto lubrication cylinders.
GALVANIZED FRAME PREVENTS CORRIOSION
Paint chips, peels and rusts over time. All Sasso machinery is hot galvanized to prevent rust and protect your investment.
TWO HYDRAULIC TILT TABLES
The K600 Twin comes with two hydraulically powered tilt tables which are mounted to the floor between the large buttressed legs.
TWO ON BOARD RED LASERS
All K600s come with two lasers. One projects a line for lining up cuts, the other is a dot for precise location of parts.
High performance laptop running Window 10 with your AlphaCam preinstalled. (We can install the software on your computer for free)
A precise probe is mounted to the saw head to measure the thickness of the slab. (Very useful if you do a lot of mitering)
TOOL MEASURING SYSTEM
Sasso has built a device that allows you to automatically measure blade diameter AND tool length (lasers don’t do a great job).
WIRELESS REMOTE PENDANT
The pendant is used for manually positioning the saw head.
OVERHEAD CAMERA WITH SLABSMITH LOCATE™
All Sasso K series saws have the option for an overhead camera.
CUTTING STANDARD SHAPES On STONE SLABS
The Sasso K600 5 AXIS CNC Saw was made for cutting slabs of stone. With a powerful variable speed 25HP direct drive motor, this machine is capable of rapid and accurate cutting of countertops and sinks. The CAD/CAM software makes programing simple and easy for the operator.
MITER LIKE A
Chip free powerful cutting.
Makes loading and unloading slabs easy!
Tight nesting and short kerf minimizes milling time, and that matters.
WITH THE SAW
Tight nesting and short kerf minimizes milling time and that matters.
FINGER BIT CUTS
SINKS & RADIUS
Faucets, sinks, radius work, engraving, and so much more.
Makes manual cutting easy and accurate.
A modern full fledge operating system on the controls of your saw.
Sasso has been building machines for the stone industry since 1974. If you need further technical information or need
a special custom configuration please contact your sales person, or email the owner of the company:
Mario Caroselli firstname.lastname@example.org.
The family at Sasso USA would like to personally thank you for considering
our equipment to increase your productivity and profitability.
