20HP K600 STANDARD

BUILT FOR CUTTING COUNTERTOPS AND so much MORE!

The fifth generation of the K600 is a fully automatic 5 Axis CNC Saw capable of rapid automated cutting of granite slabs and milling. The user-friendly touch screen allows easy programing and operation of the saw.



In addition to automated cutting and milling, this machine is a mono block design. This design allows for a smaller foot print and increased machine rigidity.



From hot galvanized frame work to the highest quality components, when you purchase a Sasso, you purchase a machine that is engineered to stand the test of time.


"Nothing standard about it...this saw kicks ass!"

20HP K600 FEATURES

the backbone of the american stone shop

The Sasso K600 5 AXIS CNC Saw was made for cutting slabs of stone. With a powerful  variable speed 20HP direct drive motor, this machine is capable of rapid and accurate cutting of countertops and sinks. The CAD/CAM software makes programing simple and easy for the operator.

BUILT TO MAINTAIN CUTTING ACCURACY

The bridge is robust post tensioned steel. The K600 5 Axis saw uses very precise servos to control the movement of the X, Y, C, A and Z axis.



FULLY ARTICULATED CUTTING AND MILLING HEAD

The cutting head rotates a full 360 degrees and miters from 0 degrees to 90. Includes M20 Adapter and 1/2 Gas Adapter



ALPHACAM CAD/CAM & COLLISION AVOIDANCE

All Sasso CNC Saws come with state of the art CAD/CAM software. The software is designed to make cutting and milling a simple, fast and productive for your machine operator.



EXCLUSIVE SASSO SUPER PLUNGE FEATURE

This revolutionary advancement allows the saw to plunge into the bed of the machine. Obtain greater slab yield as a result of tighter nesting of parts on the slab and DRAMATICALLY reduce mill time on sink corners and L shapes.

ADVANCED TOUCHSCREEN PC CONTROLS

Our large touch screen PC controls allow for orthogonal cutting, semi-automatic cutting and parametric cutting from the controls. It allows you to preview the project BEFORE you start cutting. You can access job files, the internet, remote tech support and any other tasks you can do on a computer. If you choose, you can install AlphaCam on the controls of the machine.



MILLING 3D EXOTIC SHAPES (FST SOFTWARE RECOMMENDED)

With the Sasso K600 you can make more than countertops. Three dimensional shapes can be  milled, profiled and shaped. The only limit on what you can do is your imagination.



AUTO LUBRICATION SYSTEM

All motion control axises feature auto lubrication cylinders.



GALVANIZED FRAME PREVENTS CORRIOSION

Paint chips, peels and rusts over time. All Sasso machinery is hot galvanized to prevent rust and protect your investment.



HYDRAULIC TILT TABLE

The K600 comes with a hydraulically powered one ton tilt table which is a part of the rigid mono block frame to facilitate easy loading of slabs.

TWO ON BOARD RED LASERS

All K600s come with two lasers. One projects a line for lining up cuts, the other is a dot for precise location of parts.



ADDITIONAL OPTIONS



PROGRAMING LAPTOP

High performance laptop running Window 10 with your AlphaCam preinstalled. (We can install the software on your computer for free)



SLAB PROBE

A precise probe is mounted to the saw head to measure the thickness of the slab. (Very useful if you do a lot of mitering)



TOOL MEASURING SYSTEM

Sasso has built a device that allows you to automatically measure blade diameter AND tool length (lasers don’t do a great job).



WIRELESS REMOTE PENDANT

The pendant is used for manually positioning the saw head.



OVERHEAD CAMERA WITH SLABSMITH LOCATE™

All Sasso K series saws have the option for an overhead camera.


MITER LIKE A

ROCKSTAR

Chip free powerful cutting.

HYDRAULIC

TILT TABLE

Makes loading and unloading slabs easy!

Screen Shot 2017-11-15 at 11.45.46 AM.jp
Screen Shot 2017-11-15 at 12.20.05 PM.pn

SASSO

SUPER PLUNGE

Tight nesting and short kerf minimizes milling time, and that matters.

RADIUS WORK

WITH THE SAW

Tight nesting and short kerf minimizes milling time and that matters.

Screen Shot 2017-11-15 at 12.16.46 PM.jp
Screen Shot 2017-11-15 at 11.47.41 AM.jp

FINGER BIT CUTS

SINKS & RADIUS

Faucets, sinks, radius work, engraving, and so much more.

WIRELESS

REMOTE PENDANT

Makes manual cutting easy and accurate.

Screen Shot 2017-11-15 at 12.09.20 PM.pn
Screen Shot 2017-11-15 at 12.15.00 PM.jp

WINDOWS 10

PC CONTROLER

A modern full fledge operating system on the controls of your saw.

Sasso has been building machines for the stone industry since 1974. If you need further technical information or need

a special custom configuration please contact your sales person, or email  the owner of the company:



Mario Caroselli info@sasso-usa.com



The family at Sasso USA would like to personally thank you for considering

our equipment to increase your productivity and profitability.

PROVEN PERFORMANCE...NOT A SCIENCE PROJECT

LET'S GET BUSY!
